GEO-Laser KB-80L Automatic Cone Construction Rotating Laser Level

$6,094.70
 More payment options

Notify me when back in stock

GEO-Laser KB-80L Fully Automatic Cone Construction Rotating Laser Level



The automatic cone construction laser, type KB-80L is an all-around laser for horizontal use capable of electronic self-levelling over two axes. It emits a laser beam, which turns into a cone light plane as it rotates.


FEATURES

  • Checking and adjustment
    Easily possible at the building site as well. The device does not have to be opened for adjustment.
  • Performance features
    Laser class 2, output power < 1 mW. No special safety precautions necessary. The easy standard laser class.
  • Fully automatic
    Automatic levelling and cut-out in case of low battery or jerky movements.
  • Automatic function can be switched off
    Therefore inclination adjustment by points of reference is possible.
  • Illuminated, clearly legible LCD display
    Self-explanatory, for on/off, device data, company data, lock function, operating status, battery level and menu.
  • Increased safety
    Control indicators with blinking warning system for levelling, operating status and low battery.
  • Robust metal housing
    Plastic coated, swept and filled with nitrogen, 100 % watertight.
  • Special laser beam quality
    Diode laser with visible beam, high-powered lens, high life expectancy and low power consumption.
  • Lithium ion rechargeable battery
    Operation time to 28 hours with one charge. Rechargeable in max. 5 hours without having to take out the battery.
  • Uncompromisingly easy
    All you have to do is switch on/off. The rest is done by the KB-80L automatically.



SPECIFICATIONS

Laser class 2, < 1 mW
Laser diode laser, visible red, 658 nm
Laser range up to 400 m, depending on ambient conditions, laser receiver and rotor speed
Beam diameter at laser at laser 13 mm
Self-levelling range ± 5 %
Permissible deviation 10 mm/100 m
Operating time up to 28 hours
External power supply 11 to 14 V DC with cable 0117.02
Waterproof to 3.5 m
Temperature range - 10° C to + 50° C
Weight 3.4 kg
Guarantee 24 month
Rotor speed adjustable in steps of 0 to 800 RPM



Quality Guarantee

GEO-Laser lasers are the result of decades of experience in the research, development, and production of construction lasers. The design, the materials used, as well as the rigorous quality assurance process are guarantors of high functionality and a long service life. All GEO-Laser devices are designed and manufactured exclusively in Germany and are renowned worldwide for their perfection in terms of handling, precision, robustness, and quality.
