The automatic rotary laser, type RL-78L/-79L, is an all-around laser for horizontal and vertical use capable of electronic self-levelling over 3 axes. It emits a stationary or rotating laser beam, which turns into a light plane.
| Laser class | 3R /< 5 mW |
|---|---|
| Laser | Diode visible red 658 nm |
| Laser range | to 400 m |
| Beam diameter at laser | at laser 13 mm |
| Self-levelling range | ± 5 % |
| Permissible deviation | ± 5 mm/100 m |
| Operating time | up to 28 hours |
| External power supply | 11 V DC to 14 V DC with cable 0117.02 |
| Undervoltage cut-out | yes |
| Waterproof | to 3.5 m |
| Temperature range | - 10° C to + 50° C |
| Weight | 3,4 kg |
| Guarantee | 24 month |
| Rotor speed | adjustable: 0, 100, 200, 300, 600, 800 RPM |
| Automatic function | horizontal and vertical |
| Automatic function can be switched off | yes, either one or both axes |
| Adjustment | possible in the field without having to open the device |
| Locking automatic laser light plane | up to 500 m with receiver FE-53 |
GEO-Laser's lasers are the result of decades of experience in the research, development, and production of construction lasers. The design, the materials used, as well as the rigorous quality assurance process are guarantors of high functionality and a long service life. All devices are designed and manufactured exclusively in Germany and are renowned worldwide for their perfection in terms of handling, precision, robustness, and quality.
